Application: It is suitable for electronic manufacturing, automotive circuits, precision components and other fields to improve the oxidation resistance and corrosion resistance of PCB.

Technical parameters

4. UV band main peak: 365nm

5. Strong and weak light intensity adjustment: 30%~100% (electronic power supply stepless dimming)

6. Touch screen human-machine interface control (Mitsubishi PLC)

7. Sheet metal light box installed with imported insert reflector and flat optical filter lens

8. The bottom light is fixed and the top light can be fine-tuned

9. Adopt upper and lower exhaust system

10. Conveying material: Teflon roller + stainless steel roller

11. Conveying width: 680mm

12. Conveying speed: 0~6m/min

13. Inlet height: 25mm

14. Conveying direction: operating surface from right to left

15. Power supply: 380VAC 50HZ

16. Horizontal height: 930mm

17. Exhaust outlet: 4 groups with a diameter of 250mm

18. Total exhaust volume: 140m2/min

19. Total power: 57kW
