Application: Large screen printing ink, industrial coating, paper printing

Technical parameters

1. Human-machine interface control

2. Strong and weak light intensity adjustment: 20%~100% (intelligent electronic power supply)

3. Optical reflector and optical filter lens installed on sheet metal light box

4. UV light box and lifting parts, mesh belt baffle are made of 304 stainless steel plate

5. UV light box height, electric lifting

6. Adopt the upper and lower exhaust systems

7. Conveying material: Teflon mesh belt (guide strip)

8. Conveying width: 1650mm

9. Conveying speed: 1~10m/min

10. Inlet height: 100mm

11. Power supply: 380VAC 50Hz

12. Conveying direction: operating surface from left to right
