1. UV lamp power: 6.0kw*2, 3kw*2 (UV mercury lamp)
2. Total length of UV lamp: 6.0kw: 620mm, 3kw: 300mm
3. UV band main peak: 365nm
4. Touch screen human-machine interface control (Mitsubishi brand)
5. Strong and weak light intensity adjustment: 20%~100% (stepless adjustment)
6. Sheet metal light box installed with imported insert reflector
7. UV lamp vertical, distance and angle can be adjusted
8. Adopt upper and lower exhaust system
9. Conveying material: Teflon mesh belt
10. Conveying width: 500mm
11. Conveying speed: 0~7m/min
12. Entrance height: 100mm
13. Power supply: 380VAC 50HZ
UV Curing Machine（SK-406-500P）
UV Curing Machine（SK-406-500P）
About Us Sunkun Company Strength!
- Elite engineering team of more than 10 people
- Quality assurance, no worries about delivery date
- The physical factory covers an area of 3,000 square meters
